Hytera DS6210 DMR Trunking Pro Digital Base Station
Only the technical values that differ between models are listed; identical rows are omitted. Values are taken from the manufacturer’s published data sheets.
| Property | Hytera DS6211 DMR Trunking Lite Digital Base Station | Hytera DS6210 DMR Trunking Pro Digital Base Station | Hytera DS6250S DMR Trunking Digital Base Station | Hytera DS6310 DMR Simulcast System |
|---|---|---|---|---|
| Frequency Range | UHF1: 400-470MHz; UHF2: 450-520MHz; UHF3: 330-400MHz; VHF: 136-174MHz | UHF3: 330-400MHz; UHF1: 400-470MHz; UHF2: 450-520MHz; UHF5: 806-941MHz; VHF: 136-174MHz | UHF1: 415–445 MHz; VHF: 136–174 MHz | Wireless BS: UHF1 400–470 MHz; wired BS: VHF 136–174 MHz, UHF1 400–470 MHz, UHF3 330–400 MHz |
| Weight | 8 carriers: ≤ 400 kg; 4 carriers: ≤ 200 kg | 8 carriers (42U): ≤ 314 kg; 4 carriers (29U): ≤ 165 kg | ≤16.7 kg | Single-carrier UHF: ≤ 50 kg; dual-carrier UHF or single/dual-carrier VHF: ≤ 110 kg; wireless BS: ≤ 110 kg |
| Operating Temperature | Extreme: −30°C to +60°C; normal: 15°C to 35°C | -15°C ~ +35°C | –40°C ~ +55°C | Extreme: −30°C to +60°C; normal: +15°C to +35°C |
| Standards Compliance | PDT/DMR | ETSI DMR, PDT | DMR (Tier III) | DMR |
| Carrier Capacity | 1–8 carriers (expandable to 24) | 1–16 channels (expandable to 48) | UHF: up to 8 carriers; VHF: up to 4 carriers (overall capacity table: 8, expandable to a maximum of 24) | 2 |
| Duplex Spacing | UHF5: 45 MHz; UHF1/UHF2/UHF3: 10 MHz; VHF: 5.3 MHz | UHF5: 45 MHz; VHF: 5.3 MHz; UHF3/UHF1/UHF2: 10 MHz | VHF: 5.3 MHz; UHF: 10 MHz | VHF: 5.3 MHz; UHF1/UHF3: 10 MHz |
| Power Consumption | 2 carriers: ≤ 600 W; 4 carriers: ≤ 1,200 W; 8 carriers: ≤ 2,400 W | 4 carriers: ≤ 1,000 W; 8 carriers: ≤ 2,000 W; 16 carriers: ≤ 4,000 W | UHF: ≤350 W; VHF: ≤210 W | Wired BS single-carrier (UHF): ≤ 200 W; dual-carrier (UHF) / single-carrier (VHF) / dual-carrier (VHF): ≤ 400 W; wireless BS: ≤ 400 W |
| Storage Temperature | –40°C ~ +85°C | -40°C ~ +85°C | –40°C ~ +85°C | -40°C ~ +85°C |
| MTBF | 100,000 hours | 100,000 hours | ≥ 100,000 hours | > 100,000 hours |
| Co-channel Rejection | ≥-12 dB | -12 dB ~ 0 dB | ≥ –12 dB | -12 dB ~ 0 dB (12.5 kHz) |
| Adjacent Channel Selectivity | ≥60 dB | ≥60 dB @ 12.5kHz | ≥ 60 dB | ≥60 dB (12.5 kHz) |
| Blocking | ≥84 dB @ ±1M/2M/5M/10MHz | ≥84 dB | ≥ 84 dB | ≥84 dB |
The Hytera DS6211 operates across UHF1: 400-470MHz; UHF2: 450-520MHz; UHF3: 330-400MHz; VHF: 136-174MHz. Several band versions exist; which one to buy follows from the frequency assigned to your organisation. UHF passes between walls and obstructions more readily, which is why it is preferred inside buildings, industrial plants and dense urban areas. VHF carries further over open ground and water at the same power.
Operating temperature range is Extreme: −30°C to +60°C; normal: 15°C to 35°C.
