Only the technical values that differ between models are listed; identical rows are omitted. Values are taken from the manufacturer’s published data sheets.
| Property | Hytera VM750D Smart 4G Body-Worn Camera | Hytera GC550 Ultra-Compact 2K Body-Worn Camera | Hytera SC580 Smart 4G Body-Worn Camera | Hytera SC780 Advanced 4G LTE Body-Worn Camera |
|---|---|---|---|---|
| Display | 2.8 in TFT-LCD | 2 in | 2.0 in | 2.4 in touchscreen |
| Weight | 210 g (with 3,500 mAh battery) | ≤ 115 g (including battery) | 158 g (177 g with belt clip) | 180 g (including battery) |
| Dimensions | 116 × 61 × 26 mm | 73 × 48 × 25.5 mm | 91 × 55 × 29 mm | <103 × 56 × 34 mm |
| Capacity | 3.500 mAh | 2100 mAh | 3.200 mAh | 3.200 mAh |
| Video Format | MP4 (H.264) | MP4 (H.264/HEVC) | MP4 | MP4 |
| Video Resolution | 1080p@30fps, 720p@30/60fps, 480p@30/60fps | 40MP/32MP/16MP/8MP/5MP | up to 36 MP | 36 MP |
Hytera BC47 Plastic Belt Clip
Hytera BC54 Magnetic Carry Clip
Hytera BP3504 Li-Ion Battery 3500 mAh
Hytera CH20L15 Two-Bay Charger
Hytera EHU03 C-Style Earpiece with USB Port
Hytera MCL33 Multi-Unit Charger with Data Collection
Hytera NCN025 Shoulder Strap
Hytera PC157 Data Cable, USB to Micro-USB
Hytera POA204 Base Adapter
Hytera POA215 MOLLE Mounting Attachment
Hytera PS2025 Power Adapter
Manufacturer-quoted battery life is ≥ 11 hours (720p, 30 fps, display and Wi-Fi off) on the 5/5/90 duty cycle.
Ingress protection is IP68. IP67 and above means the device withstands immersion in one metre of water. The rating only holds if the fitted battery and the accessory jack cover carry the same class; a standard battery lowers the protection of the whole assembly.
Operating temperature range is -20℃ ~ +60℃.
Location support is GPS/BDS/GLONASS/AGPS. Where position reporting will be used, the antenna has to be chosen for it as well: fit an antenna that does not cover the GPS band at 1575 MHz and the radio will communicate perfectly while showing no position on the dispatch screen.
Storage is 3.500 mAh. Actual recording time depends on resolution — 2K recording fills the same memory in roughly half the time 1080p does.
The video format is MP4 (H.264). Where footage may carry evidential weight, the format matters less than an evidence management system that preserves the integrity of the recording and a record of who accessed it.
